Weber Summit Series Replacement Instructions

3
BATTERY CASE REMOVA
L (cont.)
C) Hold the battery case and manually finish removing the nut by hand, and
then lift up on the battery case to remove from brackets. Remove the top
positive (+) and bottom negative (–) wires from the case after it is removed.
4
IGNITION MODULE REMOVA
L
A) Cut and remove the two nylon wire ties from the ignition module (1).
B) Using a phillips screwdriver remove the two mounting screws from the left
and right of the ignition module. This allows the module to swing down freely.
C) The module can be allowed to hang in place with all the wires still attached,
as shown (2).
1
TOOLS NEEDED:
- PHILLIPS
2
4
IGNITION MODULE REMOVA
L (cont.)
