15
REPLACE
CONTROL PANEL
A) Slide the back edge of the control panel in and under the fire box end cap
control panel brackets. Push the control panel all the way in and down over
valves.
TOOLS NEEDED:
- PHILLIPS
A B
A - Part# 41788
B - Part# 41787
Part # 42536
Part # 42537
B) Replace the black phillips head screw and nylon washer on the left and
right side of the control panel.
A) Replace all of the burner control knobs.
