12
cOnnectiOn OF GaS SOURce
11
FilleR StRip inStallatiOn
A) Install all front, side, and rear filler strips.
1
1
A) Make sure main gas source is completely turned off.
B) Pull main corrugated gas line through grill assembly into island structure
cavity. (Not Pictured)
C) Connect main corrugated gas line to
bulkhead fitting, which is located inside
tank enclosure (1).
DO NOT OVERTIGHTEN GAS LINE
FITTING.
To Next Page
