WEG CFW-11 Series Manual

8
ENGLISH
Table 3 - CFW-11 IP54 protection degree models electrical specification -
Heavy duty cycle (HD) application
Model
Frame
Equivalent
IP20 inverter
frame size
Rated
output
current
(1)
[Arms]
Overload
current
(2)
[Arms]
Rated carrier
frequency
(3)
[kHz]
Maximum
motor
(4)
[HP/kW]
Rated input
current
[Arms]
Dissipated
power
[W]
1 min 3 s
CFW11 0010 S 2 O 54 ...
1
A
10 15.0 20.0 5 3/2.2 20.5 140
CFW11 0006 B 2 O 54 ... 5.0 7.50 10.0 5 1.5/1.1 10.3/5.0
(5)
120
CFW11 0007 B 2 O 54 ... 7.0 10.5 14.0 5 2/1.5 14.4/7.0
(5)
140
CFW11 0007 T 2 O 54 ... 5.5 8.25 11.0 5 1.5/1.1 5.5 120 CFW11 0010 T 2 O 54 ... 8.0 12.0 16.0 5 2/1.5 8.0 170
CFW11 0013 T 2 O 54 ... 11 16.5 22.0 5 3/2.2 11.0 170
CFW11 0016 T 2 O 54 ... 13 19.5 26.0 5 4/3.0 13.0 190
CFW11 0024 T 2 O 54 ...
B
20 30.0 40.0 5 6/4.5 20.0 250
CFW11 0028 T 2 O 54 ... 24 36.0 48.0 5 7.5/5.5 24.0 290 CFW11 0033 T 2 O 54 ... 28 42.0 56.0 5 10/7.5 28.0 350
CFW11 0045 T 2 O 54 ...
2
C
36 54.0 72.0 5 12.5/9.2 36.0 450
CFW11 0054 T 2 O 54 ... 45 67.5 90.0 5 15/11
45.0 540
CFW11 0070 T 2 O 54 ... 56 84.0 112 5 20/15 56.0 680
CFW11 0086 T 2 O 54 ...
D
70 105 140 5 25/18.5 70.0 740
CFW11 0105 T 2 O 54 ... 86 129 172 5 30/22 86.0 920
CFW11 0142 T 2 O 54 ... 3 E 115 172.5 230 5
(3)
40/30 115 1280
CFW11 0003 T 4 O 54 ...
1
A
3.6 5.40 7.20 5 2/1.5 3.6 110
CFW11 0005 T 4 O 54 ... 5.0 7.50 10.0 5 3/2.2 5.0 140
CFW11 0007 T 4 O 54 ... 5.5 8.25 11.0 5 3/2.2 5.5 140
CFW11 0010 T 4 O 54 ... 10 15.0 20.0 5 6/4.5 10.0 200
CFW11 0013 T 4 O 54 ... 11 16.5 22.0 5 6/4.5 11.0 220
CFW11 0017 T 4 O 54 ...
B
13.5 20.3 27.0 5 7.5/5.5 13.5 270
CFW11 0024 T 4 O 54 ... 19 28.5 38.0 5 10/7.5 19.0 360
CFW11 0031 T 4 O 54 ... 25 37.5 50.0 5 15/11 25.0 430
CFW11 0038 T 4 O 54 ...
2
C
33 49.5 66.0 5 20/15 33.0 590
CFW11 0045 T 4 O 54 ... 38 57.0 76.0 5 25/18.5 38.0 650 CFW11 0058 T 4 O 54 ... 47 70.5 94.0 5 30/22 47.0 800
CFW11 0070 T 4 O 54 ...
D
61
91.5 122 5 40/30 61.0 1050
CFW11 0088 T 4 O 54 ... 73 110 146 5 50/37 73.0 1170
CFW11 0105 T 4 O 54 ...
3 E
88 132 176 2.5 60/45 88.0 1020
CFW11 0142 T 4 O 54 ... 115 173 230 2.5 75/55 115 1290

WEG CFW-11 Series Specifications

General

Output Voltage	0 to Input Voltage
Communication	Modbus RTU, Profibus DP, Ethernet/IP, CANopen
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Humidity	5% to 95% (non-condensing)
Enclosure Rating	IP20
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
Storage Temperature	-25 to 65 °C (-13 to 149 °F)
