4 TECHNICAL SPECIFICATIONS
Table 4.1: CPW22 technical specifications
Electrical
Operating voltage – SELV / PELV + 24 V DC / AC ± 15 %
Reverse polarity protection Yes
Frequency rated 50 / 60 Hz
Power consumption ≤ 3 VA
Response time ≤ 10 ms
Controlled voltage at S11
CA 26 to 36 V DC
DC 20 to 30 V DC
Switching current, at 24 V DC
S12 40 mA
S13 / S14 40 mA
Logic of inputs
S12 PNP
S13 / S14 NPN / PNP
Working temperature -10 to +55 °C [+ 14 to + 131 ºF]
Storage temperature -40 to +70 °C [- 40 to + 158 ºF]
Output switching Force guided relays
Safety contacts 3 NO contacts (redundant)
Auxiliary contact 1 NC contact
Switching capability
DC13 24 V DC @ 3 A
AC15 250 V AC @ 3 A
Feedback Yes
Led indicators 2, relay status K1 and K2
Mechanical
Housing material Polycarbonate PC
Dimensions 114.5 x 99 x 22.5 mm [4.50 x 3.89 x 0.88 in]
Weight ± 0.180 Kg
Connection type Screw terminals
Connection terminals
EUA 24 to 12 AWG
SI 0.5 to 2.5 mm²
Ambient temperature -10 to +55 °C [+ 14 to + 131 ºF]
Degree of protection IP 20
Degree of contamination 2
Mounting DIN rail 35 mm
Lifecycle
Electrical 2 E
6
Mechanical 1 E
7
Time life 20 years
Safety
EN ISO 13849-1
CAT 4
PL E
IEC 61508 1-7
SIL 3
PFD 6 E
-5
AVG
SFF 98 %
IEC 62061
SIL CL 3
PFHd 1 E
-9
1/h
MTTFd > 100 years
