TECHNICIANS' manual 59 of 100
12.7 EVD version
The table below shows, for each model of machine, the code
for the control unit and the reference to the page with the
wiring diagram.
Machine
Control unit
power supply
Control unit
code
Giemme
paragraph
Gicar
paragraph
ATLAS
JUN
120 V WY18363 12.7.1
230 V WY18362 12.7.1
1-2-3GR
120 V WY18090030 12.7.5 12.7.6
230-240 V WY18090031 12.7.5 12.7.6
230-240 V WY18090031A 12.7.7 12.7.8
ALTAIR
1-2-3GR
120 V WY18090030 12.7.5 12.7.6
230-240 V WY18090031 12.7.5 12.7.6
230-240 V WY18090031A 12.7.7 12.7.8
COMBINOVA
JUN
120 V WY18363 12.7.1
230 V WY18362 12.7.1
ESPRESSA
1-2-3GR
120 V WY18090017 12.7.3 12.7.4
230 V WY18090016 12.7.3 12.7.4
1-2-3GR
120 V WY18090030 12.7.5 12.7.6
230-240 V WY18090031 12.7.5 12.7.6
230-240 V WY18090031A 12.7.7 12.7.8
NOVA
JUN
120 V WY18363 12.7.1
230 V WY18362 12.7.1
1-2-3GR
120 V WY18078 12.7.2
230 V WY18079 12.7.2
4GR 230 V WY18077 12.7.2
ORION
1-2-3GR
120 V WY18090017 12.7.3 12.7.4
230 V WY18090016 12.7.3 12.7.4
1-2-3GR
120 V WY18090030 12.7.5 12.7.6
230-240 V WY18090031 12.7.5 12.7.6
230-240 V WY18090031A 12.7.7 12.7.8
POLARIS
1-2-3GR
120 V WY18090047 12.7.10 12.7.11
230 V WY18090048 12.7.10 12.7.11
POLARIS
DISPLAY
1-2-3GR
120 V WY18090079 12.7.12
230 V WY18090080 12.7.12
230 V WY18090080A 12.7.13
1-2-3GR
120 V WY18090051 12.7.14
230 V WY18090052 12.7.14
POLARIS
CUSTOMIS.
1-2-3GR 230 V WY18090315 12.7.16
Machine
Control unit
power supply
Control unit
code
Giemme
paragraph
Gicar
paragraph
SPHERA
1-2-3GR
120 V WY18090013 12.7.9
230 V WY18090012 12.7.9
4GR
120 V WY18090015 12.7.9
230 V WY18090014 12.7.9
SPHERA
DISPLAY
1-2-3-
4GR
120 V WY18090079 12.7.12
230 V WY18090080 12.7.12
230 V WY18090080A 12.7.13
START
1-2-3GR
120 V WY18090030 12.7.5 12.7.6
230-240 V WY18090031 12.7.5 12.7.6
230-240 V WY18090031A 12.7.7 12.7.8
VENERE
1-2-3GR
120 V WY18090047 12.7.10 12.7.11
230 V WY18090048 12.7.10 12.7.11
VENERE
DISPLAY
1-2-3GR
120 V WY18090079 12.7.12
230 V WY18090080 12.7.12
230 V WY18090080A 12.7.13
VELA
1-2-3-
4GR
120 V WY18090079 12.7.12
230 V WY18090080 12.7.12
230 V WY18090080A 12.7.13
