This chart is provided to help you identify the small parts used in assembly. The number in parentheses below
each part refers to the key number of the part from the PART LIST on page 18. Important: Some parts may
have been preassembled for shipping purposes. If you cannot find a part in the parts bags, check to see
if it has been preassembled.
M10 Black/Silver
Nylon Locknut (66, 76)
M6 Washer
(65)
M8 Washer
(73)
M10 Black/Silver
Washer (64, 70)
M8 Nylon
Locknut (67)
M6 x 16mm
Screw (61)
M6 x 40mm Screw (62)
M10 x 63mm Carriage Bolt (68)
M10 x 58mm Carriage Bolt (74)
M4 x 16mm
Self-tapping
Screw (75)
M10 x 65mm Bolt (55)
M10 x 55mm Bolt Set (56)
M10 x 60mm Bolt (57)
M10 x 130mm Bolt (58)
M10 x 55mm Bolt (59)
M10 x 170mm Bolt (60)
M10 x 20mm
Bolt (63)
M10 x 70mm Bolt (71)
M8 x 58mm Bolt (72)
PART IDENTIFICATION CHART
