Weider 500 - Component Identification

5
This chart is provided to help you identify the small parts used in assembly. The number in parenthesis below
each part refers to the key number of the part, from the PART LIST on page 18. The second number refers to
the quantity needed for assembly. Important: Some parts may have been pre-assembled for shipping pur-
poses. If you cannot find a part in the parts bags, check to see if it has been pre-assembled.
M10 x 60mm Bolt (18)Ñ1
M6 x 16mm Screw (15)Ñ6
M10 Washer (24)Ñ2
M8 Washer (42)Ñ4
M10 Nylon Locknut (19)Ñ2
M8 x 65mm Bolt (14)Ñ4
M8 x 50mm Bolt (17)Ñ1
M6 Washer (25)Ñ4
M8 x 55mm Bolt (41)Ñ2
M8 x 16mm Bolt (45)Ñ1
M10 x 52mm Bolt (38)Ñ1
M8 x 40mm Carriage Bolt (26)Ñ2
M6 x 38mm Screw (16)Ñ4
M8 Nylon Locknut (13)Ñ10
7mm Spacer (43)Ð1
Pulley Spacer (31)Ð2
Part Identification Chart
