Key No. Qty. Description Key No. Qty. Description
PART LIST Model No. WEBE2910.0 R0911A
Note: Specifications are subject to change without notice. For information about ordering replacement parts, see
the back cover of this manual. *These parts are not illustrated.
11Right Base
21Left Base
3 1 Center Upright
41Right Upright
51Left Upright
61Right Frame
71Left Frame
81Dip Frame
92Dip Arm
10 1 Backrest Frame
11 1 Pull-up Bar
12 1 Backrest
13 1 Right Platform Section
14 1 Center Platform Section
15 1 Left Platform Section
16 1 Short Crossbar
17 1 Medium Crossbar
18 1 Long Crossbar
19 6 14mm x 20mm Inner Cap
20 2 Armrest
21 1 Ankle Strap
22 2 Handle
23 2 Clip
24 1 Lock Pin/Tether
25 2 Upright Bushing
26 4 Cord Trap
27 2 Foot
28 2 60mm Round Inner Cap
29 2 38mm Square Inner Cap
30 2 Dome Cap
31 6 28mm Round Inner Cap
32 4 M10 x 20mm Patch Screw
33 2 50mm Round Inner Cap
34 2 45-lb. Resistance Cord
35 2 35-lb. Resistance Cord
36 2 25-lb. Resistance Cord
37 18 M6 Locknut
38 12 M6 x 72mm Bolt
39 6 M6 x 66mm Bolt
40 2 M4 x 20mm Screw
41 1 M4 x 10mm Screw
42 1 M14 x 155mm Shoulder Bolt
43 1 M12 Washer
44 1 M12 Locknut
45 12 M6 x 25mm Patch Screw
46 6 M10 x 77mm Bolt
47 12 M10 Locknut
48 16 M10 Curved Washer
49 4 M10 x 70mm Carriage Bolt
50 12 M8 x 15mm Patch Screw
51 2 M10 x 55mm Bolt
52 2 M10 x 55mm Patch Screw
53 2 M10 Washer
54 1 M8 x 25mm Socket Screw
55 2 Leveling Foot
*–Userʼs Manual
*–Assembly Tool
*–Exercise Chart
