Weider X-Factor+ User Manual

9
8. Attach the Pull-up Bar (11) to the Right and Left
Frames (6, 7) with two M10 x 55mm Patch
Screws (52) and two M10 Curved Washers
(48).
Press the two Dome Caps (30) into the Right
and Left Frames (6, 7).
See steps 4–7. Tighten the M10 Locknuts (47).
7. Identify the Right Frame (6), which is marked
with a sticker.
Attach the Right Frame (6) to the Right Upright
(4) and to the Backrest Frame (10) with two
M10 x 77mm Bolts (46), two M10 Curved
Washers (48), and two M10 Locknuts (47). Do
not tighten the Locknuts yet.
Attach the Left Frame (7) to the Left Upright
(5) and to the Backrest Frame (10) in the
same way.
7
8
6
7
46
48
4
5
47
10
11
30
30
52
52
48
48
6
7
47
