Low current (< 35 mA) Ex barrier data channel 1:
Terminal channel 1 V
out
no load V
out
with load I
out
max.
11–12 Min. 24 V Min. 12.5 V 35 mA
11–13 Min. 24 V Min. 13.5 V 35 mA
11–14 Min. 24 V Min. 14.5 V 35 mA
Low current (< 35 mA) Ex barrier data channel 2:
Terminal channel 2 V
out
no load V
out
with load I
out
max.
21–22 Min. 24 V Min. 12.5 V 35 mA
21–23 Min. 24 V Min. 13.5 V 35 mA
21–24 Min. 24 V Min. 14.5 V 35 mA
High current (< 60 mA) Ex Barrier data only one channel available on 11-14:
Terminal channel 1 V
out
no load V
out
with load I
out
max.
Min. 9 V 60 mA 11–12 Min. 24 V
Min. 11.5 V 50 mA
Min. 10 V 60 mA 11–13 Min. 24 V
Min. 12.5 V 50 mA
Min. 11 V 60 mA 11–14 Min. 24 V
Min. 13.5 V 50 mA
896540 (ACT20X-SDI-HDO-L-S), 896542 (ACT20X-2SDI-2HDO-S),
Data channel 1, 11–14
Terminal
channel 1
U
m
: VAC U
o
: VDC I
o
: mADC P
o
W L
o
mH C
o
nF V
out
no load
V
out
with load
I
out
max.
11–12 253 28 93 0.65 2.0 80 Min. 24 V Min. 12.5 V 35 mA
11–13 253 28 100 0.70 2.0 80 Min. 24 V Min. 13.5 V 35 mA
11–14 253 28 110 0.77 2.0 80 Min. 24 V Min. 14.5 V 35 mA
896542 (ACT20X-2SDI-2HDO-S),
Data channel 2, 21–24
Terminal
channel 2
U
m
: VAC U
o
: VDC I
o
: mADC P
o
W L
o
mH C
o
nF V
out
no load
V
out
with load
I
out
max.
21–22 253 28 93 0.65 2.0 80 Min. 24 V Min. 12.5 V 35 mA
21–23 253 28 100 0.70 2.0 80 Min. 24 V Min. 13.5 V 35 mA
21–24 253 28 110 0.77 2.0 80 Min. 24 V Min. 14.5 V 35 mA
