Terminal (51, 52)
Supply:
Voltage 19.2…31.2 V DC
Power max. 3 W
Terminal (53, 54)
Status Relay: Non Hazardous location Zone 2 installation
Voltage max. 125 V AC / 110 V DC 32 V AC / 32 V DC
Power max. 62.5 VA / 32 W 16 VA / 32 W
Current max. 0.5 A AC / 0.3 ADC 0.5 A AC / 1 ADC
Terminal CH1 (41, 42) CH2 (43, 44)
Digital output: NPN output:
Voltage max. 30 V DC
Current max. 80 mA
Terminal CH1 (41, 42) CH2 (43, 44)
Relay output: Non Hazardous location Zone 2 installation
Voltage max. 250 V AC / 30 V DC 32 V AC / 30 V DC
Power max. 500 VA / 60 W 64 VA / 60 W
Current max. 2 A AC / 2 ADC 2 A AC / 2 ADC
Installation notes:
DANGER
To prevent ignition of explosive atmospheres, disconnect power before servicing and do not
separate connectors when energized and an explosive gas mixture is present.
For installation in Zone 2, the module must be installed in an outer enclosure having an IP protection of at
least IP54 according to type of protection Ex-n or Ex-e.
In type of protection “intrinsic safety iD” the parameters for intrinsic safety for gas group IIB are applicable.
If the sensor circuits have been installed in a type of protection other than “intrinsic safety”, the module must
not be re-installed in type of protection ”intrinsic safety”.
