Appendix B. Installation drawings ACT20X-HTI-SAO
IECEx Installation drawing
Temperature and mA Converter ACT20X-HTI-SAO
The module is available in the following variants:
Order No. Installation Drawing
No. IECEX
Type Description
8965470000 4 50594 Bl. 3-4 ACT20X-HTI-SAO-S Temperature/mA converter
8965480000 4 50595 Bl. 4-6 ACT20X-2HTI-2SAO-S 2 ch. temperature/mA converter
DANGER
For safe installation of the Temperature and mA Converter ACT20X-HTI-SAO the following
must be observed: The module may only be installed by qualified personnel familiar with the
national and international laws, directives and standards that apply to this region.
The year of manufacture can be taken from the first two digits in the serial number.
CBX200 – WI-Manager Software
For installation in Zone 2 / Division 2 the following must be observed:
- The CBX200 is an interface cable for software.
- Configuration must be performed only in a safe area.
IECEx Certificate IECEx KEM 09.0092 X
Marking Ex nA nC IIC T4 Gc
[Ex ia Ga] IIC / IIB / IIA
[Ex ia Da] IIIC
Standards IEC60079-15: 2005, IEC60079-11: 2006, IEC60079-0: 2007
IEC60079-26: 2006, IEC61241-0: 2004, IEC61241-11: 2005
