64 1066540000/00/02.09
54
53
52
51
44
43
42
41
24
23
22
21
14
13
12
11
ACT20X
CBX200 with Configuration Software
Hazardous area
Zone 0, 1, 2, 20, 21, 22
Non Hazardous area
or Zone 2
Configuration in safe area only!
Illustration 7-18: IECEx Installation Drawing
Ex Input Supply / Output
CH1 (terminal 11, 12, 13, 14) (terminal 41…44)
CH2 (terminal 21, 22, 23, 24) (terminal 51…54)
U
o
: 8.7 V U
m
: 253 V, max. 400 Hz
I
o
: 18.4 mA
P
o
: 40 mW
L
o
/R
o
: 892 μH/Ω
IIC IIB IIA
C
o
. 5 μF 50 μF 1000 μF
L
o
. 100 mH 300 mH 700 mH
U
i
: 10 V
I
i
: 30 mA
C
i
: 30 nF
L
i
: 820 nH
