Weidmüller ACT20X - Page 65

1066540000/00/02.09 65
Terminal (53, 54)
Status Relay: Non Hazardous location Zone 2 installation
Voltage max. 125 V AC / 110 V DC 32 V AC / 32 V DC
Power max. 62.5 VA / 32 W 16 VA / 32 W
Current max. 0.5 A AC / 0.3 A DC 0.5 A AC / 1 A DC
54
53
52
51
44
43
42
41
24
23
22
21
14
13
12
11
ACT20X
CBX200 with Configuration Software
Hazardous area
Zone 0, 1, 2, 20, 21, 22
Non Hazardous area
or Zone 2
Configuration in safe area only!
-
+
Illustration 7-19: IECEx Installation Drawing
Ex Input Supply/Output
CH1 (terminal 13 +) (terminal 41…44)
CH2 (terminal 22 -) (terminal 51…54)
U
o
: 17.4 V U
m
: 253 V, max. 400 Hz
I
o
: 18.4 mA
P
o
: 80 mW
L
o
/R
o
: 445 μH/Ω
