Weidmüller ACT20X - Page 72

72 1066540000/00/02.09
44
43
42
41
54
53
52
51
24
23
22
21
14
CH1
CH2
13
12
11
ACT20X
CBX200 with Configuration Software Configuration in safe area only!
Hazardous area
Class I/II/III, Division 1, Group A,B,C,D,E,F,G
or Class I, Zone 0/1 Group IIC
Non Hazardous area or
Class I, Division 2, Group A,B,C, D T4
or Class I, Zone 2 Group IIC T4
Illustration 7-22: FM Installation Drawing
Ex Input Supply / Output
CH1 (terminal 11, 12, 13, 14) (terminal 41…44)
CH2 (terminal 21, 22, 23, 24) (terminal 51…54)
V
t
(U
o
): 8.7 V U
m
: 253 V, max. 400 Hz
It (I
o
): 18.4 mA
P
o
: 40 mW
L
o
/R
o
: 892 μH/Ω
Group IIC IIB IIA
Group A,B C,E,F D,G
C
a
/C
o.
5 μF 50 μF 1000 μF
L
a
/L
o
. 100 mH 300 mH 700 mH
