Appendix C. Installation drawings ACT20X-SDI-HDO
IECEx Installation drawing
ACT
20X-SDI-HDO Solenoid / Alarm Driver
The module is available in the following variants:
Order No. Installation Drawing
No. IECEX
Type Description
8965400000
4 51478 Bl. 3-4
ACT20X-SDI-HDO-L-S solenoid / alarm driver,
L = low current max. 35 mA
8965410000
4 51478 Bl. 3-4
ACT20X-SDI-HDO-H-S solenoid / alarm driver,
H = high current max. 60 mA
8965420000
4 51478 Bl. 3-4
ACT20X-2SDI-2HDO-S 2-channel solenoid / alarm driver,
L = low current max. 35 mA
DANGER
For safe installation of ACT20X-SDI-HDO the following must be observed: The module may
only be installed by qualified personnel familiar with the national and international laws,
directives and standards that apply to this region.
The year of manufacture can be taken from the first two digits in the serial number.
CBX200 – WI-Manager Software
For in
stallation in Zone 2 / Division 2 the following must be observed:
- The CBX200 is an interface cable for software.
- Configuration must be performed only in a safe area.
IECEx Certificate IECEx KEM 09.0071 X
Marking Ex nA nC IIC T4 Gc
[Ex ia Ga] IIC / IIB / IIA
[Ex ia Da] IIIC
Standards IEC60079-15: 2005, IEC60079-11: 2006, IEC60079-0: 2007
IEC60079-26: 2006, IEC61241-0: 2004, IEC61241-11: 2005
