896540 (ACT20X-SDI-HDO-L-S),
896542 (ACT20X-2SDI-2HDO-S),
Terminal 11–14 / 21–24
Co Lo Lo/Ro
Uo 28 V IIC 80 nF 2.9 mH 46 µH/Ω
Io 110 mA IIB 640 nF 12.8 mH 184 µH/Ω
Po 0.77 W IIA 2.1 µF 22.8 mH 369 µH/Ω
896541 (ACT20X-SDI-HDO-H-S),
Terminal 11–12
Co Lo Lo/Ro
Uo 28 V IIC 80 nF 2.69 mH 44 µH/Ω
Io 115 mA IIB 640 nF 10.8 mH 176 µH/Ω
Po 0.81 W IIA 2.1 µF 20.8 mH 353 µH/Ω
896541 (ACT20X-SDI-HDO-H-S),
Terminal 11–13
Co Lo Lo/Ro
Uo 28 V IIC – – –
Io 125 mA IIB 640 nF 9.1 mH 162 µH/Ω
Po 0.88 W IIA 2.1 µF 17.6 mH 325 µH/Ω
896541 (ACT20X-SDI-HDO-H-S),
Terminal 11–14
Co Lo Lo/Ro
Uo 28 V IIC – – –
Io 135 mA IIB 640 nF 7.8 mH 150 µH/Ω
Po 0.95 W IIA 2.1 µF 15.1 mH 301 µH/Ω
Terminal (51,52)
Supply:
Voltage 19.2…31.2 V DC
Power max. 3.5 W
Terminal CH1 (41,42) CH2 (43,44)
Input:
Voltage Max 28 V DC
Trigger: NPN Low < 2 V, High > 4 V
Trigger: PNP Low < 8 V, High > 10 V
Terminal (53,54)
Status Relay: Non Hazardous location Zone 2 installation
Voltage max. 125 V AC / 110 V DC 32 V AC / 32 V DC
Power max. 62.5 VA / 32 W 16 VA / 32 W
Current max. 0.5 A AC / 0.3 ADC 0.5 A AC / 1 ADC
