1066540000/00/02.09 85
896540 (ACT20X-SDI-HDO-L-S),
896542 (ACT20X-2SDI-2HDO-S),
Terminal 11–13 / 21–23
Co / Ca Lo / La Lo / Ro
Uo / VT 28 V IIC / A, B 80 nF 3.5 mH 50 µH/Ω
Io / Isc 100 mA IIB / C 640 nF 14.2 mH 203 µH/Ω
Po / Pt 0.70 W IIA / D, E, F 2.1 µF 27.6 mH 406 µH/Ω
896540 (ACT20X-SDI-HDO-L-S),
896542 (ACT20X-2SDI-2HDO-S),
Terminal 11–14 / 21–24
Co / Ca Lo / La Lo / Ro
Uo / VT 28 V IIC / A, B 80 nF 2.9 mH 46 µH/Ω
Io / Isc 110 mA IIB / C 640 nF 12.8 mH 184 µH/Ω
Po / Pt 0.77 W IIA / D, E, F 2.1 µF 22.8 mH 369 µH/Ω
896541 (ACT20X-SDI-HDO-H-S),
Terminal 11–12
Co / Ca Lo / La Lo / Ro
Uo / VT 28 V IIC / A, B 80 nF 2.69 mH 44 µH/Ω
Io / Isc 115 mA IIB / C 640 nF 10.8 mH 176 µH/Ω
Po / Pt 0.81 W IIA / D, E, F 2.1 µF 20.8 mH 353 µH/Ω
896541 (ACT20X-SDI-HDO-H-S),
Terminal 11–13
Co / Ca Lo / La Lo / Ro
Uo / VT 28 V IIC / A, B – – –
Io / Isc 125 mA IIB / C 640 nF 9.1 mH 162 µH/Ω
Po / Pt 0.88 W IIA / D, E, F 2.1 µF 17.6 mH 325 µH/Ω
896541 (ACT20X-SDI-HDO-H-S),
Terminal 11–14
Co / Ca Lo / La Lo / Ro
Uo / VT 28 V IIC / A, B – – –
Io / Isc 135 mA IIB / C 640 nF 7.8 mH 150 µH/Ω
Po / Pt 0.95 W IIA / D, E, F 2.1 µF 15.1 mH 301 µH/Ω
Terminal (51, 52)
Supply:
Voltage 19.2…31.2 V DC
Power max. 3.5 W
