Appendix D. Installation drawings ACT20X-HUI-SAO
IECEx Installation drawing
Universal Converter ACT20X-HUI-SAO
The module is available in the following variants:
Order No. Installation Drawing
No. IECEX
Type Description
8965490000 451481 Bl. 5-9 ACT20X-HUI-SAO-S Universal converter
DANGER
For safe installation of the Universal Converter ACT20X-HUI-SAO the following must be
observed: The module may only be installed by qualified personnel familiar with the national
and international laws, directives and standards that apply to this region.
The year of manufacture can be taken from the first two digits in the serial number.
CBX200 – WI-Manager Software
For installation in Zone 2 / Division 2 the following must be observed:
- The CBX200 is an interface cable for software.
- Configuration must be performed only in a safe area.
IECEx Certificate IECEx KEM 10.0034 X
Marking Ex nA nC IIC T4 Gc
[Ex ia Ga] IIC / IIB / IIA
[Ex ia Da] IIIC
Standards IEC60079-15: 2005, IEC60079-11: 2006, IEC60079-0: 2007
IEC60079-26: 2006, IEC61241-0: 2004, IEC61241-11: 2005
