Weidmüller ACT20X - Page 88

88 1066540000/00/02.09
54
53
52
51
44
43
42
41
24
23
22
TCRTD / LinR
mAVLoop
T
4-wire 4-wire 4-wire
Potm. 2
Potm. 3
Potm. 1
21
14
13
12
11
ACT20X-HUI
CBX200 with Configuration Software
Hazardous area
Zone 0, 1, 2, 20, 21, 22
Non Hazardous area
or Zone 2
Configuration in safe area only!
+
-
+
-
+
-
+
-
Illustration 7-27: IECEx Installation Drawing
Supply / Input
(terminal 41, 42, 43, 44)
(terminal 51, 52, 53, 54)
U
m
: 253 V, max. 400 Hz
896549 (ACT20X-HUI-SAO),
Terminal 21-24 / 22-
Co Lo Lo/Ro
Uo 28 V IIC 80 nF 4.2 mH 54 µH/Ω
Io 93 mA IIB 640 nF 16.8 mH 218 µH/Ω
Po 0.65 W IIA 2.1 µF 32.6 mH 436 µH/Ω
