Weidmüller ACT20X - Page 92

92 1066540000/00/02.09
54
53
52
51
44
43
42
41
24
23
22
21
14
13
12
11
ACT20X
ACT20X
CBX200 with Configuration Software
Hazardous area
Zone 0, 1, 2, 20, 21, 22
Non Hazardous area
or Zone 2
Configuration in safe area only!
-
+
54
53
52
51
44
43
42
41
24
23
22
21
14
13
12
11
CBX200 with Configuration Software Configuration in safe area only!
0/4-20 mA
Current source
Illustration 7-29: IECEx Installation Drawing
Supply / Input
(terminal 41, 42, 43, 44)
(terminal 51, 52, 53, 54)
U
m
: 253 V, max. 400 Hz
896549 (ACT20X-HUI-SAO),
Terminal 14-12 / 21-22
Co Lo Lo/Ro
Uo 16.6 V IIC 0.4 µF 100 mH 25 mH/Ω
Io 0.2 mA IIB 2.3 µF 100 mH 100 mH/Ω
Po 0.8 mW IIA 9.5 µF 100 mH 200 mH/Ω
