Weidmüller ACT20X - Page 91

1066540000/00/02.09 91
Supply / Input
(terminal 41, 42, 43, 44)
(terminal 51, 52, 53, 54)
U
m
: 253 V, max. 400 Hz
896549 (ACT20X-HUI-SAO),
Terminal 24-12 / 21-22
Co Lo Lo/Ro
Uo 28 V IIC 80 nF 4 mH 54 µH/Ω
Io 93 mA IIB 640 nF 16 mH 218 µH/Ω
Po 650 mW IIA 2.1 µF 32 mH 436 µH/Ω
Terminal 21–22 / 21–23
U
i
: 30 V
I
i
: 120 mA
P
i
: 900 mW
C
i
: 3 nF
L
i
: 2 µH
Terminal (53, 54)
Status Relay: Non Hazardous location Zone 2 installation
Voltage max. 125 V AC / 110 V DC 32 V AC / 32 V DC
Power max. 62.5 VA / 32 W 16 VA / 32 W
Current max. 0.5 A AC / 0.3 A DC 0.5 A AC / 1 A DC
Terminal (43, 44)
Relay Output: Non Hazardous location Zone 2 installation
Voltage max. 250 V AC / 30 V DC 32 V AC / 30 V DC
Power max. 500 VA / 60 W 64 VA / 60 W
Current max. 2 A AC / 2 A DC 2 A AC / 2 A DC
