15
January, 2017
LINEAR FEED PAN VIBRATORS
To access the linear pan vibrators located around the tower, follow the instructions below.
Remove all the water proof clips from the rubber covers. Some models do not have clips; if there are no
clips then remove the rubber covers using a flat screwdriver. Careful attention should be taken not to
puncture the rubber cover when removing them.
To access the vibrator assemblies, remove the
tower’s stainless steel cover. To remove the cover,
open all the latches surrounding it.
Removing the cover tower’s cover exposes the PrimoCombi vibrators underneath. Disconnect the
center cone vibrator’s power connector before making any adjustments.
REMOVING THE PLASTIC COVERS
OPEN ALL LATCHES
SURROUNDING THE
BASE
CENTER CONE VIBRATOR’S
POWER CONNECTOR
