GENERAL CENTER CONE SETTINGS
Description – This is the description of the configuration. It is recommended that you give the
configuration a description allowing easy recognition of the settings.
MOTOR SETTINGS
Delay to Start (ms) – This value indicates how many milliseconds to wait until the motor begins
to activate.
Center Cone Mode – This indicates how the center cone should operate with regards to the
whole system.
o Sync – Most applications should use Sync mode. This will activate the center cone when
a combination is dumped and refilling of heads is required.
o On – This will enable the center cone to be running at all times.
o Off – This will disable the center cone from running at all times.
Spin Direction – This is the first direction in which the center cone motor will spin.
o Clockwise – Rotate clockwise.
o Counter Clockwise – Rotate counter-clockwise.
On Time – This is how long the center cone motor will spin in the first direction.
