“Check sig+ wire”
The positive load cell signal was measured at either less than 1.5
volts or more than 4 volts. Check wiring at terminal marked “S1+”, check that
the load cell signal and excite pairs are correct, and finally consider that the load
cell may be damaged.
“Check sig- wire”
The negative load cell signal was measured at either less than 1.5
volts or more than 4 volts. Check wiring at terminal marked “S1-”, check that the
load cell signal and excite pairs are correct, and finally consider that the load cell
may be damaged.
11 Menus
11.1 Main Level
Power off Turn off the indicator
Production Enter the production submenu
Washdown Disable keypad to prevent false keypresses during washdown
Calibrate Enter quick calibration routine
Setup menu Bunch of stuff...see below
Audit cfg
Number of times an audited config parameter has been changed
(HB44)
Audit cal Number of times indicator has been calibrated (HB44)
Tare Current tare weight
11.2 Production
Cycle on Start automatic dump cycle
Cycle off Stop automatic dump cycle, close all gates
Cycle idle
Stop automatic dump cycle, leave all gates open for product
flowthrough (failsafe)
Target Target weight for complete batch, in pounds
Tol low Lower edge of tolerance weight range
Tol high Upper edge of tolerance weight range
Totals Display total weight, batch count, and average batch weight
11.3 Totals
Tot wgt Total gross weight, in pounds
Bat cnt Total number of batches/bags
Avg wgt Average weight of each batch/bag, in pounds
Clear totals
Clear accumulated totals (will ask you to confirm, touch “Enter” a
second time to clear)
16
