11.6 Dump settings
Target Target weight for complete batch, in pounds
Dump lmt Target weight for each dump, in pounds (hopper capacity)
Zero thrs Dump cycle zero threshold, in pounds (default is 5 pounds)
Autozero Dump cycle autozero settings (on/off)
Weigh TO How long (in seconds) to wait for a stable dump weight
Zero time How long (in seconds) to wait for an autozero to happen
Empty time
Extra time that weigh hopper will stay open after dropping below
zero threshold
Line stop How long to wait after hitting target before shutting off infeed
Shock
Number of consecutive readings above target weight before target
is reached
Filtered On/Off: Controls whether or not the target is compared to filtered
or unfiltered weight
Bag
On/Off: Controls whether or not the bag opener will extend during
the dump cycle
Dump sw
all/last/first/f+l/none: Controls whether you must press the dump
switch to release each dump, the last dump in the batch, the first
dump in the batch, the first and last dump, or none of the dumps.
Switch type
Off/Std/Rev: Controls whether or not a switch press is required to
dump (Std: N/O, Rev: N/C)
M1
Line stop/Infeed gate: select module M1 as infeed gate or a line
stop output
Tolerance
On/Off: When on, dump weight must be between (target-low) and
(target+high)
Tol low Lower edge of tolerance weight range
Tol high Upper edge of tolerance weight range
11.7 I/O test
Infeed gate Toggle infeed gate
Buffer Toggle buffer hopper gate
Weigh Toggle weigh hopper gate
Bag Toggle bag opener
Dump sw Display current state of dump switch
Wash sw Display current state of washdown switch
18
