WeighTech MicroWeigh - Load Cell Wiring Color Codes Guide; Manufacturer Specific Color Codes

15 Load Cell Color Codes
Manufacturer Models Signal + Signal - Excite + Excite - Shield Sense + Sense -
Advanced Transducers Green White Red Black Bare wire
Allegany Technology Red White Green Black Bare wire
Artech Green White Red Black
Beowulf White Red Green Black
BLH C2P1 C3P1 T2P1 T3P1 White Red Green Black Yellow
Cardinal White Red Green Black Bare wire
Celtron CSB DSR LOC SQB STC STC-SS DSR CLB HED DLB Green White Red Black Bare wire
LPS Green White Red Blue Bare wire
HOC MOC Red White Green Black Bare wire
Dillon Canister Tension Black Red Green White Orange
Compression Black Red White Green Orange
Z-cell White Green Red Black Orange
Force Measurement Green White Red Black Bare wire
GSE White Green Red Black Bare wire
HBM BLC BLF JRT PWS RSC SBF SB3 USB U1T Z6 White Red Green Black Yellow
BBS White Red Green Black Bare
PLC B35 Green White Red Black Yellow
SP4 White Red Green Black Yellow Orange Blue
Interface SSM 1200 3200 Green White Red Black Bare wire
Kubota Green Blue Red White Yellow
National White Red Green Black Yellow
NCI White Green Red Black Bare wire
Pennsylvania Green White Orange Blue Bare wire
Phillips Green Grey Red Blue Bare wire
Revere Transducer 62HU 63HU 363 953 9523 Green White Red Black Bare wire
92CC 93CC 42U 43U 263D 462 5102 5103 5123 5223
5723 6762 9102 9103 9123 9363
Green White Red Black Orange
392B 642 652 692B2 BSP HPS USP1 White Red Green Black Bare wire
792 933 SHB SSB White Red Green Black Clear
CP1 CSP1 White Red Green Black Orange
RLC Brown White Pink Grey Bare wire
Rice Lake RL20000 RL20000SS RL20001 RL20001HE RL30000
RL35023 RL35023S RL35082 RL35082S RL35083
RL39123 RL39523 RL50210 RL65044 RL70000
RL75016 RL75016SS RL75040A RL75058 RL75060
RL75223 RL90000 RLETB RLETS RLHSS RLMK4
RL50500 RL70000SS RL71000HE RL75016HE
RLMK15 RLMK21 RL75061
Green White Red Black Bare wire
RLMK1 White Green Red Black Orange Yellow Blue
RL1521 Green White Red Blue Bare wire
Sensotec White Green Red Black Bare wire
Sensortronics 60001 60008 60018 60030 60036 60040 60048 60048SS
60050 60051 60060 60060-0101 60063 65007 65016
65016SS 65016W 65023 65023S 65023SS 65024
65040A 65040S 65058 65058S 65061A 65083 65083S
65114
Green White Red Black Bare wire
60007 60064 White Red Green Black Bare wire
65088-1000 65088-1114 White Red Green Black Orange
Tedea Huntleigh 4158 Green White Red Black Bare wire
3411 3421 Green White Red Black Bare wire Blue Brown
240 1010 1022 1040 1042 1140 1250 1260 1320 9010
605 1030 1240 1241
Red White Green Black Bare wire Blue Brown
355 620 3510 White Red Blue Black Bare wire Green Grey
Toledo White Red Green Black Yellow
Weigh-Tronics White Red Green Black White/Orange
23
