WEIHONG ELECTRONIC Ncstudio User Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
Specialized, Concentrated, Focused 65
No.
Parameter
Parameter Name
Type
Remarks
12
UNIT.YR
Programming unit of
rotary axis
INT
0:angle (unit: radian)
1: surface distance of rotary
workpiece (unit: millimeter)
13
AUTOSTOPSPIN
DLE
Spindle stop when
stop
BOOL
Whether to stop spindle
automatically after machining
finishes
14
SPINDLE_DELAY
Delay when spindle
On/ Off
DOUBLE
Setting the delay time when
spindle starts/ stops automatically
15
MOBICALI_THICK
NESS
The thickness of tool
presetter in mobile
tool measurement
DOUBLE
Setting the thickness of tool
presetter in mobile tool
measurement
16
FIXEDCALI_POS.
X
The position of tool
presetter in fixed tool
measurement (X-axis)
DOUBLE
The mechanical coordinate of the
position where tool presetter
stands (X-axis) in fixed tool
measurement
17
FIXEDCALI_POS.
Y
The position of tool
presetter in fixed tool
measurement (Y-axis)
DOUBLE
The mechanical coordinate of the
position where tool presetter
stands (Y-axis) in fixed tool
measurement
18
FIXEDCALI_POS.
Z
The position of tool
presetter in fixed tool
measurement (Z-axis)
DOUBLE
The mechanical coordinate of the
position where tool presetter
stands (Z-axis) in fixed tool
measurement
19
ENABLE_CTP
Back to fixed point
valid
BOOL
Back to fixed point after the
program ends normally.
20
CTP_POS.X
The position of fixed
point (X axis)
DOUBLE
Mechanical coordinate of fixed
point（X axis）
21
CTP_POS.Y
The position of fixed
point (Y axis)
DOUBLE
Mechanical coordinate of fixed
point（Y axis）
22
CTP_POS.Z
The position of fixed
point (Z axis)
DOUBLE
Mechanical coordinate of fixed
point（Z axis）
23
BKREF_SW1.X
Port no. input of
X-axis coarse
positioning switch
INT
The signal port input of X-axis
coarse positioning switch
24
BKREF_SW1.Y
Port no. input of
Y-axis coarse
positioning switch
INT
The signal port input of Y-axis
coarse positioning switch
25
BKREF_SW1.Z
Port no. input of
Z-axis coarse
positioning switch
INT
The signal port input of Z-axis
coarse positioning switch
26
BKREF_SW2.X
Port no. input of
X-axis fine positioning
switch
INT
The signal port input of X-axis
fine positioning switch
27
BKREF_SW2.Y
Port no. input of
Y-axis fine positioning
switch
INT
The signal port input of Y-axis fine
positioning switch
28
BKREF_SW2.Z
Port no. input of
Z-axis fine positioning
switch
INT
The signal port input of Z-axis
fine positioning switch
29
BKREF_F1.X
The speed at the
coarse positioning
stage (X-axis)
DOUBLE
The feed speed of X-axis in
coarse positioning stage when
backing to the reference point
