WEIHONG ELECTRONIC Ncstudio User Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
66 Specialized, Concentrated, Focused
No.
Parameter
Parameter Name
Type
Remarks
30
BKREF_F1.Y
The speed at the
coarse positioning
stage (Y-axis)
DOUBLE
The feed speed of Y-axis in
coarse positioning stage when
backing to the reference point
31
BKREF_F1.Z
The speed at the
coarse positioning
stage (Z-axis)
DOUBLE
The feed speed of Z-axis in
coarse positioning stage when
backing to the reference point
32
BKREF_F1_DIR.X
The direction in
coarse positioning
stage (X-axis)
INT
The moving direction of X-axis in
coarse positioning stage when
backing to the reference point
33
BKREF_F1_DIR.Y
The direction in
coarse positioning
stage (Y-axis)
INT
The moving direction of Y-axis in
coarse positioning stage when
backing to the reference point
34
BKREF_F1_DIR.Z
The direction in
coarse positioning
stage (Z-axis)
INT
The moving direction of Z-axis in
coarse positioning stage when
backing to the reference point
35
BKREF_F2.X
The speed of X-axis in
fine positioning stage
DOUBLE
The feed speed of X-axis in fine
positioning stage when backing to
the reference point
36
BKREF_F2.Y
The speed of Y-axis in
fine positioning stage
DOUBLE
The feed speed of Y-axis in fine
positioning stage when backing to
the reference point
37
BKREF_F2.Z
The speed of Z-axis in
fine positioning stage
DOUBLE
The feed speed of Z-axis in fine
positioning stage when backing to
the reference point
38
BKREF_F2_DIR.X
The direction of X-axis
at the fine positioning
stage
INT
The moving direction of X-axis in
fine positioning stage when
backing to the reference point
39
BKREF_F2_DIR.Y
The direction of Y-axis
at the fine positioning
stage
INT
The moving direction of Y-axis in
fine positioning stage when
backing to the reference point
40
BKREF_F2_DIR.Z
The direction of Z-axis
at the fine positioning
stage
INT
The moving direction of Z-axis in
fine positioning stage when
backing to the reference point
41
BKREF_BACK.X
The retract distance of
X-axis
DOUBLE
The additional moving distance of
X-axis after fine positioning stage
during backing to the reference
point
42
BKREF_BACK.Y
The retract distance of
Y-axis
DOUBLE
The additional moving distance of
Y-axis after fine positioning stage
during backing to the reference
point
43
BKREF_BACK.Z
The retract distance of
Z-axis
DOUBLE
The additional moving distance of
Z-axis after fine positioning stage
during backing to the reference
point
44
CALIBRATION_S
W
Port no. input of tool
calibration signal
INT
Specifying port no. input of tool
calibration signal
45
SPINDLE_START
_PORT
Port no. output of
spindle
INT
Specifying port no. output of
signal for spindle on/off
46
COOLANT_STAR
T_PORT
Output port no. for
coolant liquid pump
INT
Specifying the output port no. of
signal for coolant on/off
