5.3.2.5 Wiring Diagram of Delta Servo Drive
Delta ASDA-A, ASDA-B, ASDA-B (one-to-two), and ASDA-B2 servo drives use the same
type of cables.
Wiring diagrams are as follows:
 Delta ASDA-A
