Weishaupt W-FM 200 User Manual

Installation and operating instruction
Combustion manager W-FM 100 und W-FM 200
6 Operation
83054802 1/2018-07 La
126-228
6.12.7 Analogue output
Param & Display LoadController Configuration Analog output
or
Param & Display SystemConfig LC Analog Output
The analogue outputX63 is configured in menu Analog Output, see
[ch.3.4.10].
Stipulate output value (OutValuSelection)
Parameter OutValuSelection stipulates the value that is output as a current
signal at outputX63
Setting Function
Load
(1
Load 0
Load signal from internal load controller
O2 Residual oxygen content in flue gas
Pos Air
Pos fuel
Pos Aux…
Position of the relevant actuator
Speed VSD Setpoint speed
Flame Flame Signal
Temp Pt…
Temp Ni1000
Temperature sensor input X60
Temp X61
Press X61
Temperature/ pressure sensor input X61
(1
Current range, output value and scaling are predefined and can not be changed
[ch.3.4.10].
Current range (CurrMode 0/4mA 0/4mA)
Parameter CurrMode 0/4mA defines the current range at outputX63.
0..20mA
4..20mA
