Combustion manager W-FM 100 und W-FM 200
7 Commissioning
83054802 1/2018-07 La
155-228
7.2 Adjusting the burner
In addition to this chapter, the information about adjustment in installation and oper-
ating manual of the burner should be observed. This manual contains detailed in-
formation about:
speeds (in in conjunction with frequency converter),
pump pressure,
flow and return pressure,
default settings,
mixing pressure.
7.2.1 Preparatory measures
In addition to this chapter, the information about adjustment in installation and oper-
ating manual of the burner should be observed.
Prerequisite
Remove mixing head drive rod (only on burners with adjustable mixing head).
Set fuel selection switch to Gas (only on dual fuel burners with heavy oil).
Switch on voltage supply.
1. Switch off burner
The ABE is in OperationalStat in the sub menu NormalOperation and dis-
plays current values.
Exit level using the [esc] key.
Select ManualOperation.
Select Autom/Manual/Off.
Set Burner Off.
The burner switches off.
Exit level using the [esc] key.
2. Enter password
Select Param & Display.
Select Access with HE (password for heating engineer).
Enter HE password using dial knob and confirm with [ENTER] [ch.6.2.1].
3. Check drive rod of mixing head
Only on burners with adjustable mixing head.
Isolate fan motor from voltage supply.
Prevents fan starting during this step.
Select RatioControl.
Select GasSettings or OilSettings.
Select SpecialPositions.
Select HomePos.
select HomePosAux1 and set 0.0°.
Refit drive rod and check stop (play 1…2 mm).
Remove drive rod again.
Select HomePosAux1 and set 90.0°.
Refit drive rod and check stop (play minimum 1mm).
Return HomePosAux1 to 0.0° setting.
Reconnect voltage supply to motor.
Exit level using the [esc] key.
