Weishaupt W-FM 200 User Manual

Installation and operating instruction
Combustion manager W-FM 100 und W-FM 200
3 Product description
83054802 1/2018-07 La
20-228
3.2.7.4 Heavy oil direct ignition
(5 (5
7970 72 74 76 786260544438363432302422212012100100 4240
X4-01:2
X3-04:1
X10-...
(2
X3-02:1
X4-01:3
X5-01:2
X5-02:2
X3-01:1
X6-02:3
X4-02:3
7970 72 74 76 786260544438363432302422212012100100 4240
7970 72 74 76 786260544438363432302422212012100100 4240
X4-03:3
(6
X6-03:3
X8-02/03
X7-02:3
X7-01:3
(1
(1
(3
(3
(3
(4
(4
X6-01:1
X6-01:3
(5
(5
1
3
2
Lockout phase
Safety phase
Home run
Standby
Start-up
Start release
Fan ON
Pre-purge position
Pre-purge
Ignition position
Pre-ignition
Fuel release
Ignition OFF
Flame Signal
Partial load position
Operating setting 1 Operating setting 2
Post burn time
Post-purge position
Post-purge
Direct start
Inputs
Fuel selection
Safety circuit
Heat demand
Flame Signal
Air pressure switch
Fan contactor contact
Minimum oil pressure switch
Max. oil pressure switch
Start release Oil
Outputs
Burner motor / Fan
Ignition
Pressure switch release
Start signal
Anti syphon valve
Fuel valve 1
Fuel valve 2
Actuators
Full load
Pre-purge position
Post-purge position
Partial load
Ignition position
Standby position
Fuel valve 3
Magnetic coupling / Oil pump
Heavy oil immediate start
(1
Signal only required to jump to Phase 79 (direct start)
(2
with QRI / QRA7x: Input X10-02:6
with QRA2: Input X10-03:1
with QRB: Input X10-02:1
(3
Only with continuous running fan
(4
Signal depends on parameter: OnIgnPointOilIgnition (long or short pre-ignition)
(5
Signal depends on parameter: OilPumpCoupling (direct coupling)
(6
Signal depends on parameter: Start/PS valve
