Rotary indexing ring TR
Introduction
■
Operation in residential environments
■
Operation in life-supporting systems
■
Operation in potentially explosive atmospheres/hazardous areas
■
Operation on ships, in rail vehicles, land craft or in aircraft
■
Operation in military facilities
■
Operation outside of the specified order data
■
Applications involving transportation of persons (fairground rides)
1.4 Applicable documents
In addition to these mounting instructions, the following documents are binding for and apply to any
type of use of the product:
■
Order data (including, but not limited to, design data, load data, performance data, transportation
and storage instructions, information attached to the product and the package, as well as other
specifications).
■
Documentations of the manufacturers of all products belonging to the scope of delivery (for example,
motor, accessories, attachment parts). This includes, among other things:
DeliveryType of manual Type Manufacturer
Paper format Electronic
Operating and mainte-
nance instructions
Motor
IEC low voltage squirrel cage
asynchronous motors en-
closed version
Končar – MES d.d. - X
Data sheet Inductive sensor
PNP, NBB2-8GM40-E2-V3
Pepperl+Fuchs-
Gruppe
- X
Data sheet Inductive sensor
PNP, NBB4-12GM30-E2-V1
Pepperl+Fuchs-
Gruppe
- X
Data sheet Inductive sensor
NPN, NBB4-12GM30-E0-V1
Pepperl+Fuchs-
Gruppe
- X
Data sheet Inductive sensor
NPN, 3RG4011-7GB33-PF
Pepperl+Fuchs-
Gruppe
- X
Data sheet DRIVE-CliQ encoder
6FX2001-5FD25-1AA0
SIEMENS AG - X
Safety data sheet Lubricant
Shell Omala S2 G 680
Shell Deutschland
Oil GmbH
- X
Safety data sheet Lubricant
Shell Gadus S2 V220AD 2
Shell Deutschland
Oil GmbH
- X
