Rotary indexing ring TR
Technical data
4.9 Load data
Load data for output flange
Characteristic Unit TR0750A TR1100A TR1500A TR2200A
Torque at standstill Nm 2500 3500 5000 15000
Permissible moment of tilt during
movement
Nm 2500 3500 3200 4500
Permissible axial force during
movement
N 7000 12000 16000 30000
Permissible radial force during
movement
N 7000 12000 16000 30000
26 / 79
Mounting instructions_062019_4.0_en
