Page 15
OPERATION–Feeding the Welding Wire
For the MIG 100, MIG 120 and MIG 160
Press the trigger switch to engage the MIG weld-
ing wire feed and wait until the wire is automati-
cally fed through the wire hose, ensuring the
feeding tube is straight and not coiled, as this
may cause a wire blockage.
If the welding wire fails to feed, recheck that the
correct procedure for Feeding the Welding Wire
has been followed.
For the MIG 100, MIG 120 and MIG 160
If the steps above have been followed and fails to
rectify the problem, remove the silver coloured
welding nozzle and copper contact tip as illus-
trated to the left, and check that the welding wire
is feeding without obstruction. Re-assemble the
contact tip and the nozzle.
For the MIG 100, MIG 120 and MIG 160
Checking the wire feed. Switch the welder on as
shown.
