ASSEMBLY INSTRUCTIONS
For the MIG 160
Slide the right wheel and axle into position. At-
tach the left wheel onto the axle and insert the R
Clips to retain wheels.
For the MIG 160
Fit the trolley base into position and secure with
screws.
For the MIG 120 and MIG 160
Slide the handle into the grooves on top of the
machine and secure with screws.
For the MIG 160
Slide the handle extension through the handle
and secure with screw.
Page 9
For the MIG 160
Attach gas bottle support and secure with screws.
