STARTING THE ARC
Hold the torch with the wire approximately 2 mm
from the work piece. Press the torch trigger to
begin welding.
STARTING THE ARC
TECHNIQUES
Effect of Electrode Wire Position and Welding Technique
PUSH PERPENDICULAR DRAG / PULL
10
10
DIRECTION OF WELDING
Electrode
wire
directed
ahead of
bead
Electrode
wire
pointed
back into
bead
Push
Technique
Gun Perpendicular
Technique
Drag / Pull
Technique
