OPERATION—Fitting the Gas Bottle
For the MIG 120 and MIG 160
Clean dust and dirt from the gas bottle nipple.
Open the gas knob for a few seconds to release
some gas. This will avoid any remaining dust get-
ting into the regulator. Attached the appropriate
regulator as pictured.
For the MIG 120 and MIG 160
Insert the hose into the gas bottle as pictured,
secure as required.
For the MIG 120 and MIG 160
Secure the bas bottle in position as pictured onto
the welder, ensuring that the excess hose is inside
the welders casing.
For the MIG 120 and MIG 160
Insert the hose onto the welders gas valve as pic-
tured. This is located inside the casing of the weld-
ers.
Page 16
NOTE: WHEN THE WELDER IS NOT IN USE, ALWAYS CLOSE THE GAS BOTTLES
VALVE AND ZERO OUT THE REGULATOR.
NOTE: GAS BOTTLE IS NOT INCLUDED
