i16 Manual Page 31 - Revision: 2-09-2023
Bracket Fastening
1. Place the bracket on the wall at the installation site and mark
the positions (x2).
*There is only one bracket that could be fixed on the top or
bottom side of the Stand.
2. Drill two holes in the marked position to fix the bracket to the
wall.
3. Ensure the unit is fixed with the wall-mounted bracket, so that
the unit does not fall if pushed.
