i16 Manual Page 33 - Revision: 2-09-2023
Ice Bin Cleaning
Preparation:
- Prepare a cleaning solution by mixing 0.2L of cleaning agent with 4L of clean water.
- Prepare additional 4L of clean water for rinsing operation
- Prepare a soft cloth and sanitary gloves.
STEP 1: Draining the water and ice
1. Turn off the Hot Water Switch located at the rear of the unit.
2. Shut off the water supply valve, so that no water can come into the unit.
3. Empty completely all ice from the system using the Ice Dispense Button.
4. Empty completely all water from the Reservoir Tank using the Water Dispense Button.
*Do NOT drain the Hot Water
5. Connect the drain hose to the Drain Valve (located at the bottom & front side), and then
proceed to drain remaining water. Once completed, remove the drain hose.
STEP 2: Disassembling the unit
6. Remove the Water Tray and remove the Top Cover & Front Cover by loosening the fixing
screws. Set aside the front cover (*Be mindful of the wire that is attached)
7. Remove the Ice Tank Cover by loosening the fixing screws, and then remove 2 augers by
pulling them upward, take care not to lose the caps of the augers. (During the re-assembling
of spirals, please pay attention to the shape of the joint).
To Next Page
