Owner’s Manual
HPC-3000 / WPC-4000 / HPC-5000 / WPC-7000 / WPC-9000 / WPC-15000
Cool air outlet hose
Front and Right Side View
Display / Control board
Top fan exhaust flange
Evaporator / filter
Guide bar for condensate water tank
Condensate water tank (Water level is
sensed, and the unit operaon is stopped
when tank is full. An alarm will be
displayed. Empty the tank and replace to
resume operaon)
Figure 21
Figure 20
Figure 22
Figure 24
Back and Le Side View
Condenser / filter
Power cord holder
Caster
Electrical access
panel
Figure 23
Figure 25
1. Remove cool air outlet hose(s) from
carton.
2. Place the cool air outlet hose(s) on
the front top of air condioner.
3. Use screws (enclosed inside of box
with cool air outlet hose(s) to install
the cool air outlet hose(s) on the air
condioner as shown in Figure 24.
An ambient air adapter can be
purchased separately. Air adapte
r fits
over the condenser to duct
condenser air to the unit to improve
cooling efficiency.
1. Remove air adapter from carton.
2. Place air adapter on the side of air
condioner.
3. Use screws (enclosed inside of bo
x
with air adapter) to install the
adapter on the air condioner as
shown in Figure 25.
1. Take out the cord holder from
the accessory box.
2. Place the cord holder on the
back side of air condioner.
3. Use screws (enclosed inside of
accessory box with cord holder)
to install the cord holder on the
air condioner as shown in
Figure 22.
1. Remove the top fan exhaust
flange from carton.
2. Place the top fan exhaust flange
on the top of air condioner.
3. Use screws (enclosed inside of
box with the top fan exhaust
flange) to install the top fan
exhaust flange on air condioner
as shown in Figure 23.
Component Parts
POWER CORD HOLDER
TOP FAN EXHAUST FLANGE
DISCHARGE DUCTS
/SUPPLY AIR DUCT
AMBIENT AIR ADAPTER
(Oponal)
Cool air outlet
Front and Right Side View
Display / Control board
Top fan exhaust flange
Evaporator / filter
Condenser / filter
Figure 27
Figure 26
Figure 28
Figure 29
Back and Le Side View
Condenser / filter
Power cord holder
Caster
Electrical access panel
Drain pump hose connector
Handle
Drain pump included
Figure 30
Figure 31
1. Remove cool air outlet hose(s) from
carton.
2. Place the cool air outlet hose(s) on
the front top of air condioner.
3. Use screws (enclosed inside of box
with cool air outlet hose(s) to install
the cool air outlet hose(s)
on the air condioner as shown in
Figure 29.
1. Take out the cord holder
from the accessory box.
2. Place the cord holder on
the back side of air condioner.
3. Use screws (enclosed inside of
accessory box ith cord
holder)to install the cord
holder on the air condioner
as shown in Figure 28.
EXHAUST FLANGE
1. Remove the top fan exhaust flange from carton.
2. Place the top fan exhaust flange on the top of air condioner.
3. Use screws (enclosed inside of box with the top fan exhaust flange)
to install the top fan exhaust flange on air condioner as shown in Figure 30.
AMBIENT AIR ADAPTERS (Oponal)
Ambient air adapters can be purchased separately. Air
adapter fits over the condenser to duct condenser air to
the unit to improve cooling efficiency.
1. Remove air adapters from cartons.
2. Place air adapters on the both side of air condioner.
3. Use screws (enclosed inside of box with air adapter) to
install the adapter on the air condioner as shown in
Figure 31.
POWER CORD HOLDER
DISCHARGE DUCTS
/SUPPLY AIR DUCT
Component Part
s
ASSEMBLY(WPC-15000)
