Owner’s Manual
HPC-3000 / WPC-4000 / HPC-5000 / WPC-7000 / WPC-9000 / WPC-15000
ASSEMBLY(HPC-3000)
Condenser / filter
Figure 2 – Rear and Le Side View
Cool air outlet hose
Display / Control board
Top fan wire grille
Evaporator / filter
Guide bar for
condensate
water tank
Condensate water tan
k
(Water level is sensed, and th
e
unit operaon is stopped when
tank is full. An alarm will be
displayed. Empty the tank an
d
replace to resume operaon)
Figure 1 – Front and Right Side View
Power cord holder
Electrical access panel
Casters
