No. Part No. Description
48 36055-048 Frame
49 36055-049 Pivot Pin
50 36055-050 Spring
51 36055-051 Spring Holder
52 36055-052 Riving Knife Holder
53 36055-053 Riving Knife
54 36055-054 Head Screw
55 36055-055 Blade
56 36055-056 Dust Connector
57 36055-057 Frame Cover
58 36055-058 Screw
59 36055-059 Countersunk Screw
60 36055-060 Outer Saw Blade Flange
61 36055-061 Inner Saw Blade Flange
62 36055-062 Screw
63 36055-063 Spring
64 36055-064 Connecting Rod - Riving Knife
66 36055-066 Pointer
68 36055-068 Guider
69 36055-069 Depth Scale
70 36055-070 Pressing Part
71 36055-071 Knob
72 36055-072 Cylinder Head Screw M6x12
73 36055-073 Washer
74 36055-074 Knob
75 36055-075 Head Screw
76 36055-076 Knob
77 36055-077 Left Tilting Guider
78 36055-078 Bottom Plate
79 36055-079 Right Tilting Guider
80 36055-080 Grub Screw for 45 Degree Stop
NP 36053C Clamp (sold separately)
17
EXPLODED VIEW AND PARTS LIST
No. Part No. Description
1 36055-001 Power Cord
2 36055-002 Hexagon Stud Wrench
3 36055-003 Carbon Brush Spring
4 36055-004 Carbon Brush Holder
5 36055-005 Motor Housing
6 36055-006 Rubber Protection Tube
7 36055-007 Cord Pressing Plate
8 36055-008 Screw 4.2x13
9 36055-009 Attachment
10 36055-010 Handle
11 36055-011 Screw 7x24
12 36055-012 Stator
13 36055-013 Screw
14 36055-014 Front Cover
15 36055-015 Rubber Gil
16 36055-016 Switch
17 36055-017 Capacitor
18 36055-018 Switch Button
19 36055-019 Locking Button
20 36055-020 Reset Spring
21 36055-021 Locking Button Spring
22 36055-022 Switch Button Spring
24 36055-024 Carbon Brushes (2)
25 36055-025 Back Cover
26 36055-026 Rubber Sleeve for Bearing
27 36055-027 Bearing
28 36055-028 Rotor
29 36055-029 Bearing
30 36055-030 Shaft Locking Part
31 36055-031 Spring for Lock Bar
33 36055-033 Head Screw
34 36055-034 Cutting Lock
35 36055-035 Gear Box
38 36055-038 Screw
39 36055-039 Gear Box Cover
40 36055-040 Flathead Countersunk Screws
41-42 36055-041 Shaft
43 36055-043 Bearing Cover
44 36055-044 Screw
45 36055-045 Bearing 6002
46 36055-046 Retaining Ring for Shaft
47 36055-047 Screw
TRACK EXPLODED VIEW (36027)
No. Part No. Description
1 36027-001 Bottom Rubber Strip
2 36027-002 Bottom Foam Strip
3 36027-003 Guiding Rail
4 36027-004 Top Plastic Strip
5-6 36027-005 Stabilizer
7-8 36027-007 Stopper
13-14 36027-013 Track Adaptor
