Wen 3625 User Manual

EXPLODED VIEW & PARTS LIST
No. Part No. Description Qty.
1 3625-001
Screw With Washer
M4x14
5
2 3625-002 Spindle Lock Button 1
3 3625-003 Spindle Lock Spring 1
4 3625-004 Gear Housing 1
5 3625-005 Baffle D4 1
6 3625-006
Square Neck Bolt
M6×26
2
7 3625-007 Bearing 698 1
8 3625-008 Spiral Bevel Gear 1
9 3625-009 Ball Bearing 3
10 3625-010 Gear Shaft 1
11 3625-011 Bearing 607-2z 4
12 3625-012 C-Clip 2
13 3625-013 Spacer 1
14 3625-014 Intermediate Shaft 1
15 3625-015 Large Gear 1
16 3625-016 O-Ring 2
17 3625-017 C-Clip 1
18 3625-018 Pinion 1
19 3625-019 Spacer Sleeve 1
20 3625-020 C-Clip 2
21 3625-021 Bearing 699 1
23 3625-023 Dust Hose Assembly 1
25 3625-025
Self-Tapping Screw
ST4.2×14
6
27 3625-027 Cover 2
35 3625-035 Laser Assembly 1
No. Part No. Description Qty.
39 3625-039 Blade Arbor 1
40 3625-040 Fixed Blade Guard 1
41 3625-041
Screw With Washer
M4x12
2
42 3625-042
Cross-Shaped Screw
M4x12
1
43 3625-043
Rubber Block For
Lower Guard
1
44 3625-044
Screw For Rubber
Block
1
33 3625-033 Blade Arbor Screw 1
34 3625-034 Left Label 1
35 3625-035 Left Housing 1
36 3625-036 Screw St4.2x12 1
37 3625-037 Lever For Blade Cover 1
38 3625-038 Reset Spring 1
39 3625-039
Screw For Reset
Spring
1
40 3625-040
Screw With Washer
M4x12
2
41 3625-041 Power Switch Button 1
42 3625-042 Spindle Lock Cap 1
43 3625-043 Spindle Lock Spring 2
44 3625-044
Screw For Rubber
Block
1
45 3625-045 Blade Cover 1
46 3625-046 Baffle 1
47 3625-047 Inner Flange 1
48 BL11510W Blade, TCT, 115 mm 1
19
