No. Part No. Description Qty.
49 3625-049 Blade Arbor Screw 1
50 3625-050 Outer Flange 1
51 3625-051 Screw St4.2x12 1
52 3625-052 Lever For Blade Cover 1
53 3625-053 Left Label 1
54 3620-057 Left Housing 1
55 3625-055
Screw For Reset
Spring
1
56 3625-056 Reset Spring 1
57 3620-067 Switch Locking Button 1
58 3620-076 Switch Trigger 1
59 3625-059 Spindle Lock Spring 2
60 3625-060
Switch Terminal In-
sert, 4.8x0.8
2
61 3620-075 Power Switch 1
62 3620-037 Connecting Rod 1
63 3620-038 Bearing 609-2z 1
64 3620-039 C-Clip 1
65 3620-041 Connecting Sleeve 1
66 3620-042 Stator Assembly 1
67 3620-038 Bearing 608-2z 1
68 3620-043 Rotor Assembly 1
69 3620-044
Brush Terminal Insert,
2.8x0.8
2
70 3625-070
Self-Tapping Screw
With Washer
ST2.9×10
2
No. Part No. Description Qty.
71 3620-046 Lower Brush Holder 1
72 3620-045 Carbon Brush 2
73 3620-048 Bearing 606-2z 1
74 3620-049 Bearing Sleeve 1
75 3620-050 Upper Brush Holder 1
76 3625-076
Self-Tapping Screw
With Washer
ST4.2×16
9
77 3620-092 Right Housing 1
78 3625-078 Right Label 1
79 3625-079 Power Cord Sheath 1
80 3625-080 Hex Wrench 1
81 3625-081 Power Cord 1
82 3625-082 C-Clip for Shaft D10 2
83 3625-083 Depth Locking Lever 2
84 3625-084 M6 Locking Pin 2
86 3625-086 Flat Washer M6 2
87 3625-087 Screw M6x12 1
88 3625-088
Rip Fence Locking
Spring
1
89 3625-089 Base Plate 1
90 3625-090
Cylindrical Spring Pin
D6x35
1
91 3625-091 Rip Fence 1
92 3625-092 Cord Clamp 1
93 3625-093 Relay 1
EXPLODED VIEW & PARTS LIST
20
