Wen 3920 User Manual

21
EXPLODED VIEW & PARTS LIST
Item Stock # Description
1 3920B-001
Screw M5X8
2 3920B-002 Screw ST4.2X10
3 3920B-003 Side cover
4 3920B-004 Nut 6
5 3920B-005 Spring Washer 6
6 3920B-006 Base
7 3920B-007 Oil Cap
8a 3920B-008a Left Arm Housing
8b 3920B-008b Right Arm Housing
9 3920B-009 Tension Bolt Assembly
10 3920B-010 Extension Spring
11 3920B-011 Pressure Plate
12 3920B-012 Spring Washer 4
13 3920B-013 Screw M4X10
14 3920B-014 Lower Arm
15 3920B-015 Upper Arm
16 3920B-016 Arm Bearing
17 3920B-017 Blast Pipe
18 3920B-018
Screw M5X6
19 3920B-019 Flexible Led Assembly
20 3920B-020 Spring Washer 5
21 3920B-021 Screw M5X35
22 3920B-022 Screw M4X6
23 3920B-023 Bellows Cap
24 3920B-024 Screw M5X28
25 3920B-025 Table Lock Knob
26 3920B-026 Switch Fixing Board
27 3920B-027 Switch
28 3920B-028 Bellows
29 3920B-029 Fixing Plate
30 3920B-030 Bolt M6X20
31 3920B-031 Upper Blade Support
32 3920B-032 Washer 4
33 3920B-033 Screw M4X16
34 3920B-034 Clamping Board
35 3920B-035 Blade 15TPI
36 3920B-036 Screw M5X25
37 3920B-037 Big Cushion
38 3920B-038 Eccentricity Connector
39 3920B-039 Bearing 625Z(80025)
40 3920B-040 Nut M5
41 3920B-041 Clamping Board
42 3920B-042 screw ST4.2X9.5
43 3920B-043 Washer
44 3920B-044 Screw M5X16
45 3920B-045 Wrench S3
46 3920B-046
Drop Foot Lock Knob
47 3920B-047 Drop Foot Fixing Pole
Item Stock # Description
48 3920B-048 Screw M5X30
49 3920B-049 PCB
50 3920B-050 Drop foot
51 3920B-051 Flat Washer 6
52 3920B-052 Screw M6X10
53 3920B-053 PVC Pipe
54 3920B-054 Big Washer 6
55 3920B-055 Screw M6X40
56 3920B-056 screw M6X20
57 3920B-057 Washer 6
58 3920B-058 Spring
59 3920B-059 Screw M6X35
60 3920B-060 Work Table Bracket
61 3920B-061 Pointer
62 3920B-062 Bevel Scale
63 3920B-063 Work Table
64 3920B-064 Work Table Insert
65 3920B-065 Speed Adjusting Knob
66 3920B-066 Screw M5x6
67 3920B-067 Power Cord
68 3920B-068 Screw M4X8
69 3920B-069 Screw M8X12
70 3920B-070 Eccentric Wheel
71 3920B-071 Motor
72 3920B-072 Switch Box
73 3920B-073 Cord Clamp
74 3920B-074 Screw M4X10
75 3920B-075 Potentiometer
76 3920B-076
Blade (PIN) 18TPI
77 3920B-077 Screw M6X10
78 3920B-078 Screw M5X8
79 3920B-079 Holder Handle
80 3920B-080 Spring Washer 6
81 3920B-081 Wire Clip 1
82 3920B-082 Wire Clip 2
83 3920B-083 Screw M4X6
84 3920B-084 Transformer Box
85 3920B-085 Circuit Board
86 3920B-086 Screw ST2.9X6.5
87 3920B-087 Cord Bushing 1
88 3920B-088 Cord Bushing 2
89 3920B-089 LED Lamp
90 3920B-090 LED Wire
91 3920B-091 Tool Box
92 3920B-092 Bolt M8X20
93 3920B-093 Bolt M6X80
94 3920B-094
Nut M4
