Wen 3962

EXPLODED VIEW & PARTS LIST
22
No. Part No. Description Qty.
1 3962-001 Blade Tension Knob 1
2 3962-002 Bushing 1
3 3962-003 Retaining Ring 1
4 3962-004 Frame Cap 1
5 3962-005 Spring 1
6 3962-006 Nut 1
7 3962-007 Retaining Ring 2
8 3962-008 Shaft 1
9 3962-009 Guide Plate 2
10 3962-010 Pulling Plate 1
11 3962-011 Hex Head Bolt 4
12 3962-012 Flat Washer 8
13 3962-013 Hex Nut 4
14 3962-014 Bevel Block 1
15 3962-015 Shaft 1
16 3962-016 Ball Bearing 4
17 3962-017 Retaining Ring 4
18 3962-018 Upper/Lower Wheel 2
19 3962-019 Retaining Ring 2
20 3962-020 Tire 2
21 3962-021 Blade 1
22 3962-022 Upper Cover 1
23 3962-023 Lower Cover 1
24 3962-024 Nut 2
25 3962-025 Bushing 2
26 3962-026 Socket Head Bolt 2
27 3962-027 Frame 1
28 3962-028 Nut 1
29 3962-029 Flat Washer 1
30 3962-030 Led Driver 1
31 3962-031 Socket Head Bolt 1
32 3962-032 Serrated Washer 2
33 3962-033 Pan Head Screw 2
34 3962-034 Switch Box 1
No. Part No. Description Qty.
35 3962-035 Connecting Terminal 2
36 3962-036 Switch Cover 1
37 3962-037 Led Switch 1
38 3962-038 Main Switch 1
39 3962-039 Pan Head Screw 2
40 3962-040 Nut 1
41 3962-041 Flat Washer 1
42 3962-042 Bushing 1
43 3962-043 Flat Washer 1
44 3962-044 Brush 1
45 3962-045 Carriage Blot 1
46 3962-046 Hex Nut 1
47 3962-047 Spindle Pulley 1
48 3962-048 Socket Head Bolt 3
49 3962-049 Cord Bushing 2
50 3962-050 Limiting Shaft 1
51 3962-051 Hex Nut 1
52 3962-052 Knob Cap 1
53 3962-053 Tracking Set Knob 1
54 3962-054 Tracking Lock Knob 1
55 3962-055 Guide Block 2
56 3962-056 Pan Head Screw 2
57 3962-057 Lock Nut 2
58 3962-058 Cover Lock Knob 2
59 3962-059 Socket Head Bolt 2
60 3962-060 Shaft 1
61 3962-061 Gear 1
62 3962-062 Knob Insert 1
63 3962-063
Upper Guide
Adjusting Knob
1
64 3962-064 Spring 1
65 3962-065 Lock Knob 1
66 3962-066 Lower Guard 1
67 3962-067 Socket Head Bolt 2
