Wen 56380i

TABLE OF CONTENTS
Introduction ....................................................................................2
Safety Information ...........................................................................4
Generator Safety Warnings ..............................................................5
Know Your Generator .......................................................................8
Generator Preparation ...................................................................10
Starting the Generator ...................................................................16
Using the Generator ......................................................................18
Shutting Off the Generator .............................................................23
Maintenance .................................................................................24
Transportation & Storage ...............................................................32
Troubleshooting Guide ...................................................................33
Specifications ...............................................................................34
Wiring Diagram .............................................................................35
Exploded View & Parts List ............................................................36
Warranty Statement ......................................................................47
KEY SPECIFICATIONS
Wattage 3800 Surge Watts, 3400 Rated Watts
Phase Single
Frequency 60Hz
Rated Voltage
AC: 120V
DC: 12V (Cigar Lighter), 5V (USB)
Rated Amperage
AC: 28.3A (Total), 28.3A (TT-30R), 20A (5-20R)
DC: 10A (Total), 8A (Cigar Lighter), 1A/2.1A (USB)
Oil Capacity 18.6 fl. oz. (0.55 L)
Half-Load Run Time 8.5 hours
Battery 1.6 Ah Lithium-Ion
Product Dimensions 23.2 x 18 x 20.1 in. (L x W x H)
Product Net Weight 99.2 lbs (45 kg)
2
Your WEN 56380i generator is compatible with the WEN 56421 Parallel Connection Kit
and the WEN 55201 Magnetic Oil Dipstick, available for purchase at wenproducts.com
